Model	TP-LINK Omada SG6428XHP 24-PortGigabit Stackable L3 Managed PoE+ Switch with 4 10GE SFP+ Slots

HARDWARE FEATURES :
Interface	24× 10/100/1000 Mbps PoE+ RJ45 Ports
	4× 10G SFP+ Slots
	2× USB 2.0 Ports
	1× RJ45 Console Port
	1× USB Type-C Console Port
	1× RJ45 Management Port

Fan Quantity	Four Field-replaceable and Hot-swappable Fans

Power Supply	Two Field-replaceable and Hot-swappable Power Supply Modules** (100–240 VAC, 50/60 Hz)
	**Shipping with one PSM500-AC module by default, and another field-replaceable redundant power
	supply requires purchasing separately.

PoE Ports (RJ45)	Standard: 802.3at/af compliant
	PoE+ Ports: 24 Ports, up to 30 W per port
	PoE Power Budget: up to 720 W*

Max Power Consumption	42.9 W (110 V/60 Hz) (With no PD connected)
	916.6 W (110 V/60 Hz) (With 720 W PD connected and powered by 2× PSM500-AC)

Max Heat Dissipation	146.29 BTU/hr (110 V/60 Hz) (With no PD connected)
	3,125.61 BTU/hr (110 V/60 Hz) (With 720W PD connected and powered by 2× PSM500-AC)

Mounting	Rack Mountable

Dimensions ( W x D x H )	17.3 × 16.5 × 1.7 in (440 × 420 × 44 mm)

PERFORMANCE :
Switching Capacity	128 Gbps per Unit

Stacking	Stacking Number: 4
	Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports)
	Stack Bandwidth: 20 Gbps Per Port (Full-Duplex)

Packet Forwarding Rate	95.2 Mpps

MAC Address Table	32 K

Packet Buffer Memory	3 MB

Jumbo Frame	9 KB

SOFTWARE FEATURES :
Quality of Service	• Class of Service
	- 8 Queues of Priority
	- Port Priority
	- IEEE 802.1p Priority
	- DSCP Priority
	- Queue Min-Bandwidth
	- Schedule Mode (SP, WRR, SP+WRR)
	• Bandwidth Control
	- Rate Limit
	- Storm Control
	• Voice VLAN
	• User-Defined OUI
	• Smoother Performance
	• Action for Flows
	- QoS remark (802.1P Remark, DSCP Remark)

VLAN	• Max 4K VLAN Group (802.1q VLAN)
	• 802.1Q Tagged VLAN
	• MAC VLAN Entries: 200
	• Multicast VLAN
	• Management VLAN
	• VLAN VPN (QinQ): Max 256 entries
	• GVRP
	• Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries
	• VLAN VPN
	• Voice VLAN
	• Private VLAN

MANAGEMENT :
Omada App	Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada
	Software Controller.

Centralized Management	Omada Cloud-Based Controller
	Omada Hardware Controller
	Omada Software Controller

Cloud Access	Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada
	Software Controller.

Zero-Touch Provisioning	Yes. Requiring the use of the Omada Cloud-Based Controller.

OTHERS :
Package Contents	SG6428XHP Switch
	Power Cord
	RJ45 Console Cable
	Quick Installation Guide
	Rackmount Kit
	Rubber Feet

System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.

Environment	Operating Temperature: 0–45 ℃ (32–113 ℉);
	Storage Temperature: -40–70 ℃ (-40–158 ℉)
	Operating Humidity: 10–90% RH non-condensing
	Storage Humidity: 5–90% RH non-condensing

Warranty	Limited Lifetime Warranty

TPLink Omada SG6428XHP Specification
