| Standards | IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (Security Authentication), 802.1Q (VLAN), |
| 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) | |
| Cabling type | Category 5e or better |
| Antennas | Internal antennas optimized for installation on desktop |
| Led indicators | 1 multifunction LED |
| Operating system | Linux |
| Ports | 10/100/1000 Ethernet, with support for 802.3af /at PoE, power port for AC adapter (included) |
| Power supply | External 12V/1A DC power jack (Energy Star 2.0 compliant with Efficiency Level 6) and 802.3af/at PoE |
| Buttons | Reset button, power on/off push button |
| LEDs | 1 LED |
| Wireless throughput | Up to 867-Mbps data rate (real-world throughput will vary) |
| Recommended user support | Up to 64 connective users, 10 active users |
| Frequency | Dual bands (2.4 and 5 GHz) |
| Radio technologies | technologies 802.11b: Direct-Sequence Spread-Spectrum (DSSS) |
| 802.11a/g/n/ac: Orthogonal Frequency Division Multiplexing (OFDM) | |
| Modulation types | 802.11b: BPSK, QPSK, CCK |
| 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM | |
| WLAN | 802.11ac/n |
| 2x2 Multiple-Input Multiple-Output (MIMO) with 2 spatial streams at 5 GHz | |
| 2x2 MIMO with 2 spatial streams at 2.4 GHz | |
| 20-, 40-, and 80-Mhz channels for 802.11ac | |
| 20 and 40 MHz for 802.11n | |
| PHY data rate up to 867Mbps | |
| Data rates supported | 802.11a/b/g: |
| ● 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, and 1 Mbps | |
| ● 802.11n: 6.5 to 300 Mbps | |
| ● 20-MHz bandwidth: MCS 0-15 for supported data rates | |
| ● 40-MHz bandwidth: MCS 0-15 for supported data rates | |
| ● 802.11ac: 6.5 to 867 Mbps | |
| ● 20-MHz bandwidth: MCS 0-9 for supported data rates | |
| ● 40-MHz bandwidth: MCS 0-9 for supported data rates | |
| ● 80-MHz bandwidth: MCS 0-9 for supported data rates | |
| Dimensions | 4.85 x 4.85 x 1.25 in. (123 x 123 x 31 mm) |
| Weight | 0.67 lb (303 g) |
