Name: TPLink Omada BE9300 Series
Brand: CISCO
SKU: EAP772
Availability: InStock

Model	[EAP772] TP-LINK Omada BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point

HARDWARE FEATURES :
Interface	1× 2.5G Ethernet Port

Button	Reset

Power Supply	802.3at PoE or 12V/2.5A DC

Power Consumption	• 24.05 W (For PoE);
	• 20.92 W (For DC)

Dimensions ( W x D x H )	8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)

Antenna Type	• 2.4 GHz: 2× 4.0 dBi
	• 5 GHz: 2× 5.0 dBi
	• 6 GHz: 2× 5.0 dBi

Bluetooth	1 × 4.0 dBi, Bluetooth 5.2
	*Firmware update may be required.

Mounting	Ceiling / Wall Mounting (Kits Included)

WIRELESS FEATURES :
Coverage	140㎡(1500 ft²)***

Wireless Client Capacity	380+**

Wireless Standards	IEEE 802.11 a/b/g/n/ac/ax/be

Frequency	6 GHz, 5 GHz, and 2.4 GHz

Signal Rate	688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz) + 5765 Mbps (6 GHz)†

Wireless Functions	• MLO‡
	• 4K-QAM‡
	• Seamless Roaming(802.11k/v/r)
	• MU-MIMO‡
	• EHT320‡
	• Mesh△
	• BSS Coloring‡
	• OFDMA‡
	• Load Balance
	• Band Steering
	• Beamforming
	• Airtime Fairness
	• Multiple SSIDS:24(8 on each band)
	• Wireless Schedule
	• Reboot Schedule
	• QoS(WMM)
	• Rate Limit
	• Static IP/Dynamic IP
	• RADIUS Accounting
	• MAC Authentication

Wireless Security	• Captive Portal Authentication
	• Access Control
	• Maximum number of MAC Filter: 4,000
	• Wireless Isolation Between Clients
	• VLAN
	• Rogue AP Detection
	• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Transmission Power	< 20 dBm (2.4 GHz, EIRP)
	< 23 dBm (5 GHz, band 1&band 2, EIRP)
	< 28 dBm (5 GHz, band 3, EIRP)
	< 23dBm (6 GHz, EIRP)
MANAGEMENT :
Omada App	Yes

Centralized Management	• Omada Cloud-Based Controller
	• Omada Hardware Controller (OC300)
	• Omada Hardware Controller (OC200)
	• Omada Software Controller

Cloud Access	Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.

Email Alerts	Yes

LED ON/OFF Control	Yes

Management MAC Access Control	Yes

SNMP	v1, v2c, v3

System Logging Local/Remote Syslog	Yes

Web-based Management	Yes

OTHERS :
Certification	CE, FCC, RoHS, IC

Package Contents	• EAP772
	• Installation Guide
	• Ceiling/Wall Mounting Kit
	Note: Power Adapter is NOT included.

Environment	• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
	• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
	• Operating Humidity: 10%–90% non-condensing;
	• Storage Humidity: 5%–90% non-condensing;

Warranty	Limited Lifetime Warranty

TPLink Omada BE9300 Series Specification
