| Model : | |
|
Name
|
TS5400DN |
| Hardware : | |
|
Type
|
Desktop |
| OS | Linux Original |
| CPU | Intel Atom D2550 |
| Clock | 1.86GHz |
| Memory | DDR3 2GB |
| Internal Hard Drives : | |
|
Number of Drives
|
4 |
| Drive Interface | SATA II |
| Supported RAID Levels | 0, 1, 5, 6,10, JBOD (Normal) |
| Drive Capacity | TS5400D (Enclosure) |
| TS5400DN0404(4TB) | |
| TS5400DN0804(8TB) | |
| TS5400DN1204(12TB) | |
| TS5400DN1604(16TB) | |
| LAN Interface : | |
|
Standard Compliance
|
IEEE802.3/3u/3ab |
| Speed and Flow Control | 10/100/1000 Mbps (Auto Sensing) |
| Number of Ports | 2 x RJ-45 (Auto MDIX) |
| USB Interface : | |
|
Standard Compliance
|
USB 2.0 / USB 3.0 |
| Connector Type | A type |
| Number of Ports | 2 x USB2.0 / 2 x USB3.0 |
| UPS Interface : | |
|
Standard Compliance
|
D-Sub 9pin |
| Number of Ports | 1 |
| Key Feature : | |
|
iSCSI
|
Y |
| IP Camera | Y |
| Hot Spare | Y |
| Hot Swap | Y |
| Replication | Y |
| Failover | Y |
| Amazon S3 | Y |
| Port Trunking | Y |
| Disk Quota | Y |
| Virus Scan | Option |
| Protocol Support : | |
|
Networking
|
TCP/IP |
| File Sharing | CIFS/SMB, AFP, HTTP/HTTPS, FTP/FTPS, SFTP, NFS |
| Directory Integration | LDAP, Active Directory |
| Management | HTTP/HTTPS |
| Time Synchronization | NTP |
| Other : | |
|
Client OS Support
|
Windows® RT 8.1 / RT |
| Windows® 8.1 / Windows® 8 / Windows® 7 / Windows Vista™ (32/64bit) | |
| Windows® XP | |
| Windows Server® 2012/ 2008 R2/ 2008/ 2003/ 2000 | |
| Mac OS® X 10.5 - 10.10 | |
| Power Consumption | 60W (Average), 86W (Max) |
| Dimensions (LxWxH, ) | 215 x 170 x 230 |
| Weight | 8.0 kg |
| Operating Environment | 5-35°C, 20-80% (non-condensing) |
| Power Supply | AC 100-240V, 50/60Hz |
| Warranty | 3-year |
| Package Contents : | |
|
Contents
|
TeraStation 5400DN (TS5400DN) |
| Setup CD‑ROM | |
| LAN Cable | |
| AC Cable | |
| Front Panel Key | |
| Quick Setup Guide | |
| Warranty Statement |
