Model |
[TS-h1886XU-RP-R2-D1622-32G] QNAP TS-h1886XU-RP-D1622-32G 18-bay Rackmount NAS with ZFS-based QuTS hero |
|
|
Form Factor |
Rackmount |
|
|
CPU |
Intel® Xeon® D-1622 4-core processor, burst up to 3.2 GHz |
|
|
System Memory |
32GB UDIMM DDR4 ECC (2 x 16GB) |
|
|
Maximum Memory |
128 GB (4 x 32 GB) |
|
|
Memory Slot |
4 x UDIMM DDR4 |
|
|
Flash Memory |
5GB (Dual boot OS protection) |
|
|
Drive Bay |
Front: 12 x 3.5-inch SATA 6Gb/s, 3Gb/s |
|
Rear: 6 x 2.5-inch SATA 6Gb/s, 3Gb/s |
|
|
Drive Compatibility |
3.5-inch bays: |
|
3.5-inch SATA hard disk drives |
|
2.5-inch SATA solid state drives |
|
2.5-inch bays: |
|
2.5-inch SATA solid state drives |
|
|
Hot-swappable |
Yes |
|
|
SSD Cache Acceleration Support |
Yes |
|
|
SR-IOV |
Yes |
|
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
4 (2.5G/1G/100M) |
|
|
10 Gigabit Ethernet Port |
2 x 10GbE SFP+ SmartNIC port |
|
Pre-installed with a 10GbE PCIe adapter |
|
|
Wake on LAN (WOL) |
Yes |
|
|
Jumbo Frame |
Yes |
|
|
PCIe Slot |
3 |
|
Slot 1: PCIe Gen 2 x4 (x8 Slot) |
|
Slot 2: PCIe Gen 3 x4 |
|
Slot 3: PCIe Gen 3 x8 or x4 (x8 Slot) |
|
|
USB 3.2 Gen 1 port |
2 |
|
|
Power Supply |
Redundant PSU |
|
|
LED Indicators |
HDD, SSD, Status, LAN, storage expansion port status |
|
|
Buttons |
Power, Reset |
|
|
Dimensions (HxWxD) |
88.6 × 432 × 511.2 mm |
|
|
Weight (Net) |
14.5 kg |
|
|
Weight (Gross) |
18.6 kg |
|
|
Warranty |
3 Years Carry-in |
