| Product SKUs | SuperServer 7049P-TR (Black) |
| Processor | Dual Socket P (LGA 3647) |
| Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s | |
| Support CPU TDP 70-205W | |
| Cores Up to 28 Cores with Intel® HT Technology | |
| System Memory | Memory Capacity 16 DIMM slots , Up to 2TB ECC 3DS LRDIMM, 512GB ECC RDIMM, DDR4 up to 2666MHz |
| Memory Type 2666/2400/2133MHz ECC DDR4 SDRAM | |
| On-Board Devices | Chipset Intel® C621 chipset |
| SATA SATA3 (6Gbps); RAID 0, 1, 5, 10 | |
| Network Controllers Dual 1GbE LAN with Intel® X722 | |
| IPMI Support for Intelligent Platform Management Interface v.2.0,IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | |
| Video ASPEED AST2500 BMC | |
| Input / Output | SATA 8 SATA3 (6Gbps) ports |
| LAN 2 RJ45 Gigabit Ethernet LAN ports ,1 RJ45 Dedicated IPMI LAN port | |
| USB Rear USB: 2 USB 3.0 + 2 USB 2.0 , Front USB: 2 USB 2.0, USB Header: 1 Type A | |
| Video 1 VGA port | |
| Serial Port / Header 2 Fast UART 16550 serial , 2 COM Ports (1 rear, 1 header) | |
| DOM 2 SuperDOM (Disk on Module) ports | |
| Expansion Slots | 4 PCI-E 3.0 x16 slots |
| 2 PCI-E 3.0 x8 slots | |
| Support total of 6 Full-height AOC | |
| Drive Bays | 8 Hot-swap 3.5" SATA3 drive bays |
| 3 Peripheral 5.25" drive bays | |
| Power Supply | 1280W Redundant High-efficiency Digital Power Supplies w/ PMBus 1.2 |
| Form Factor | 4U Rackmountable / Tower |
| Dimensions (WxDxH ) | 178 x 648 x 452 mm |
