| Form Factor/Height | 2U Rack |
| Processor /Cache | Up to two Intel® Xeon® processors E5-2600 v3 series with up to 18 cores each/Up to 45 MB per processor |
| Memory | Up to 1.5 TB with SK Hynix 64 GB TruDDR4 Memory LRDIMMs; System supports RDIMM/LRDIMM |
| Disk Bays | Up to 24 front and 2 rear 2.5-inch HDDs/SSDs; or up to 12 3.5-inch and 2 rear 3.5-inch HDDs + 2 rear 2.5-inch |
| HDDs/SSDs; or up to 8 3.5-inch HDDs and 2 rear 3.5-inch or 2.5-inch HDDs/SSDs (model dependent) | |
| RAID Support | 12 Gbps dedicated slot for the first RAID; support for up to four RAID adapters |
| Power Supply | Up to 1/2 redundant 550 W AC, 750 W AC, 900 W AC, 1500 W AC, 900 W DC 80 PLUS® Platinum, or 750 W AC |
| 80 PLUS Titanium | |
| Hot-Swap Components | Power supplies, fan modules, and HDDs/SSDs |
| Network Interface | 4 x 1 GbE (std) and 1 x IMM; optional 10/40 GbE ML2 or PCIe adapter; Trusted Platform Module built-in |
| Expansion Slots | 1 – 8 PCIe 3.0 slots (supports up to 2 x 300 W GPUs and up to 1 x ML2) and 1 dedicated RAID slot |
| USB Ports/VGA Ports | Up to 3 front (1 x USB 3.0, 2 x USB 2.0) and 4 back (2 x USB 3.0, 2 x USB 2.0) and 1 internal (USB 3.0) for |
| hypervisor/1 front and 1 back | |
| Internal Storage | Up to 100 TB |
| Energy Efficiency | 80 PLUS® Platinum, 80 PLUS Titanium; ENERGY STAR compliance (model dependent) |
| Systems Management | IMM2.1; one IMM dedicated port and one shared; optional remote presence; Predictive Failure Analysis; LEDs; |
| optional next-gen light path diagnostics panel | |
| Operating Systems (OS) Supported | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere (Optional |
| USB Key or SD Media Adapter) |
