APC Smart UPS SMX
P/N : SMX750I
Name : APC Smart UPS SMX
ราคา : 21,617฿ [ inc. VAT 23,130฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    750VA / 600Watts
  • POWER FACTOR :
    0.80
  • BACKUP TIME :
    14 min. Full Load / 37 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Rack/Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
Technical Specification
opology Line Interactive
Output Power Capacity 800 Watts / 1.0 kVA
Nominal Output Voltage 230V
Nominal Input Voltage 230V
Typical recharge time 3 hour(s)
Output Connections (8) IEC 320 C13 (Battery Backup)
Control panel Multi-function LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Weight 22.86 KG
Warranty 3 Yrs./ Onsite Swap

Output

  • Output Voltage Distortion
    Less than 5%
  • Output Frequency (sync to mains)
    50/60Hz +/- 3 Hz
  • Output Connections
    (8) IEC 320 C13 (Battery Backup)
  • Max Configurable Power (Watts)
    600 Watts / 750 VA
  • Output power capacity
    600 Watts / 750 VA
  • Topology
    Line Interactive
  • Waveform type
    Sine wave

Input

  • Cord Length
    1.83 meters
  • Number of Power Cords
    1
  • Input frequency
    50/60 Hz +/- 3 Hz (auto sensing)
  • Input voltage adjustable range for mains operation
    151 - 302 V
  • Input voltage range for main operations
    160 - 286 V
  • Input Breaker Capacity
    0 A
  • Other Input Voltages
    220, 240
  • Input Connections
    IEC-320 C14
  • Rack Height
    2 U

Battery

  • Battery Slots Empty
    1
  • Included Battery Modules
    1
  • Typical recharge time
    3 hour(s)
  • Battery type
    Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
  • DC Overcurrent Protection
    60 A
  • RBC Quantity
    1
  • Battery Volt-Amp-Hour Capacity
    312
  • Runtime
  • Efficiency

Communication

  • Audible Alarm
    Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
  • Control panel
    Multi-function LCD status and control console
  • Available SmartSlot™ Interface Quantity
    1

Runtime

  • Output power capacity
    600 Watts / 750 VA

Surge

  • Filtering
    Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

  • Color
    Black
  • Maximum Depth
    490 mm , 49.0 CM
  • Maximum Height
    89 mm , 8.9 CM
  • Net Weight
    22.05 KG
  • Units per Pallet
    8.0
  • Rack Height
    2 U
  • Shipping Depth
    620 mm , 62.0 CM
  • Shipping Height
    246 mm , 24.6 CM
  • Shipping weight
    26.5 KG
  • Shipping Width
    589 mm , 58.9 CM
  • Maximum Width
    432 mm , 43.2 CM

Environmental

  • Audible noise at 1 meter from surface of unit
    40.0 dBA
  • Operating Temperature
    0 - 40 °C
  • Operating Elevation
    0-3000 meters
  • Operating Relative Humidity
    0 - 95 %
  • Storage Temperature
    -15 - 45 °C
  • Storage Elevation
    0-15000 meters
  • Storage Relative Humidity
    0 - 95 %
  • Online thermal dissipation
    69.0 BTU/hr
  •



P/N : SMX1000I
Name : APC Smart UPS SMX
ราคา : 28,009฿ [ inc. VAT 29,970฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    1000 VA / 800 Watts
  • POWER FACTOR :
    0.80
  • BACKUP TIME :
    8 min. Full Load / 24 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
P/N : SMX1500RMI2U
Name : APC Smart UPS SMX
ราคา : 39,935฿ [ inc. VAT 42,730฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    1500 VA / 1200 Watts
  • POWER FACTOR :
    0.80
  • BACKUP TIME :
    5 min. Full Load / 17 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Rack/Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
P/N : SMX2200RMHV2U
Name : APC Smart UPS SMX
ราคา : 51,075฿ [ inc. VAT 54,650฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    2200 VA / 1980 Watts
  • POWER FACTOR :
    0.90
  • BACKUP TIME :
    9 min. Full Load / 25 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Rack/Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
P/N : SMX3000HV
Name : APC Smart UPS SMX
ราคา : 65,766฿ [ inc. VAT 70,370฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    3000 VA / 2700Watts
  • POWER FACTOR :
    0.90
  • BACKUP TIME :
    6 min. Full Load / 18 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Rack/Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
P/N : SMX3000HVNC
Name : APC Smart UPS SMX
ราคา : 82,636฿ [ inc. VAT 88,421฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    3000VA / 2700Watts
  • POWER FACTOR :
    0.90
  • BACKUP TIME :
    6 min. Full Load / 18 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Rack/Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
P/N : SMX1500RMI2UNC
Name : APC Smart UPS SMX
ราคา : 38,500฿ [ inc. VAT 41,195฿ ]
Call Stock
  • APC Smart UPS SMX Specification

  • xxxdawdawd
  • RATING :
    1500VA / 1200Watts
  • POWER FACTOR :
    0.8
  • BACKUP TIME :
    6 min. Full Load / 17 min. Half Load
  • TECHNOLOGY :
    Line Interactive
  • MANAGEMENT :
    -
  • CHASSIS :
    Tower
  • WARRANTY :
    3 Yrs./ Onsite Swap
