DESCRIPTION | SPECIFICATIONS |
Host Interface |
6Gbps SAS or 1/10Gbps iSCSI or 8Gbps Fibre Channel
|
Single/Dual Controller |
Single- and Dual- (active/active) controller support
|
RAID Support |
RAID 1, 5, 6, 10
|
Fans and Power Supplies |
Fully redundant and hot swappable
|
Supported Drives |
2.5-inch SAS Drives: 300GB, 600GB at 15,000rpm
|
2.5-inch SAS Drives: 600GB, 900GB, 1.2TB at 10,000rpm | |
2.5-inch NL-SAS SED Drives: 600GB, 900GB, 1.2TB at 10,000rpm | |
2.5-inch NL-SAS Drives: 1TB at 7,200rpm | |
2.5-inch SAS SSD: 400GB, 800GB, 1.6TB | |
3.5-inch NL-SAS Drives: 2TB, 4TB, 6TB, 8TB at 7,200rpm | |
3.5-inch NL-SAS SED Drive: 4TB at 7,200rpm | |
Cache per Controller |
6GB per controller (Data (Read/Write) cache = 4GB and Metadata and System OS cache = 2GB)
|
LUNs per System |
1024 maximum and 128TB LUN size
|
Snapshots per Volume |
254 maximum
|
Expansion Units (3 max) |
E1012: 12 x 3.5-inch drives, E1024: 24 x 2.5-inch drives
|
Snapshots |
64 included
|
Optional Licenses |
Intelligent Real-Time Tiering with SSDs, 256 snapshots, 512 snapshots, asynchronous replication
|
Asynchronous Replication | Up to 32 volumes |
Scheduler supports 1hr, 12hr, and 24hr time intervals | |
Licenses: one for target and one for source | |
Warranty |
3-year limited warranty, 9x5 next business day parts only
|
ENERGY STAR Certified |
The Lenovo Storage S2200 is now ENERGY STAR certified. ENERGY STAR-certified
|
products are energy efficient which results in cost savings via reduced energy | |
consumption and regulatory rebates. Please refer to the US EPA website for details on | |
ENERGY STAR certification criteria and process. Lenovo Storage S2200 | |
ENERGY STAR certification is listed on the EPA website. |
