Model	Cisco Aironet 1815i Series Access Points

Software	● Cisco Unified Wireless Network Software with AireOS Wireless Controllers Release 8.4 or later
	● Cisco Mobility Express (future availability)

Maximum clients	● Maximum number of associated wireless clients: 200 per Wi-Fi radio, in total 400 clients per access point

802.11ac	● 2x2 single-user/multiuser MIMO with two spatial streams
	● Maximal ratio combining (MRC)
	● 20-, 40- and 80-MHz channels
	● PHY data rates up to 866.7 Mbps (80 MHz on 5 GHz)
	● Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Rx)
	● 802.11 Dynamic Frequency Selection (DFS)
	● Cyclic shift diversity (CSD) support

Ethernet ports	● Authentication with 802.1X or MAC filtered
	● Dynamic VLAN or per port
	● Traffic locally switched or tunneled back to wireless LAN controller

Bluetooth (future availability)	● Integrated Bluetooth 4.1 (including BLE) radio
	● Maximum transmit power: 4 dBm
	● Antenna gain: 2 dBi

Integrated antennas	● 2.4 GHz, gain 2 dBi
	● 5 GHz, gain 4 dBi

Interfaces	● 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE)
	● Management console port (RJ-45)

Indicators	● Status LED indicates boot loader status, association status, operating status, boot loader warnings,
	boot loader errors

System	● 1 GB DRAM
	● 256 MB flash
	● 710 MHz quad core

Input power requirements	● Power injector: AIR-PWRINJ5= or AIR-PWRINJ6=

Powering options	● 802.3af/at Ethernet switch
	● Optional Cisco power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=)
	● 8.3W (maximum, on PoE)

Mounting	● Included with the access point: mounting bracket AIR-AP-BRACKET8

Dimensions (W x L x H)	● Access point (without mounting bracket): 6 x 6 x 1.3 in (150.8 x 150.8 x 33 mm)

Weight	● Access point without mounting bracket or any other accessories: 14 oz (400 g)

Cisco Aironet 1815 Series Specification
