| Product | TS-EC2480U-R2 |
| Form Factor | 4U, Rackmount |
| CPU | TS-EC2480U-E3-4GE-R2: Intel® Xeon® E3-1246 v3 Quad-core processor |
| TS-EC2480U-i3-4GE-R2: Intel ® Core i3-4150 processor | |
| TS-EC2480U-i3-8G-R2:Intel® Core i3-4150 processor | |
| Memory | Total memory slots: 4 |
| TS-EC2480U-E3-4GE-R2/ TS-EC2480U-i3-4GE-R2: | |
| System memory: 4 GB DDR3 ECC RAM | |
| Memory module pre-installed: 2 GB x2 | |
| Memory expandable up to: 32 GB (8GB x4) | |
| TS-EC2480U-i3-8G-R2: | |
| System memory: 8 GB DDR3 non-ECC RAM | |
| Memory module pre-installed: 4 GB x2 | |
| Memory expandable up to: 32 GB (8GB x4) | |
| Flash Memory | 512MB DOM |
| Internal Cache Port | Two mSATA port on board for read caching |
| Note: The standard system is shipped without mSATA flash. | |
| Hard Drive | 24 x 3.5-inch SATA 6Gbps/3Gbps hard drive or 2.5-inch SATA, 6Gbps/3Gbps hard drive SSD hard drive |
| Hard Drive Tray | 24 x hot-swappable and lockable tray |
| LAN Port | Built-in 2 x 10 GbE SFP+ ports (LAN-10G2SF-MLX) and 4 x GbE ports 40GbE is optional |
| LED Indicators | Status, 10 GbE, LAN, eSATA, storage expansion port status |
| USB | 4x USB 3.0 port (rear) |
| 4x USB 2.0 port (rear) | |
| Support USB printer, pen drive, USB hub, and USB UPS etc. | |
| Buttons | System: Power button and reset button |
| Power | Sleep mode: 129.43 |
| In Operation: 263.81 W | |
| (with 24 x HITACHI HUS724020ALA640 hard drive installed) | |
| Dimensions | 176.15(H) x 442.5(W) x 530.5(D) mm |
| 6.94(H) x 17.42(W) x 20.89(D) inch | |
| Weight | Net weight (NAS only) : 23.08 kg/50.88 lb |
| Gross weight (with packing and accessories) : 28.56 kg/ 62.96 lb | |
