| Model : | |
|
Name
|
TS3200D |
| Hardware : | |
|
Type
|
Desktop |
| OS | Linux Original |
| CPU | Marvell ARMADA XP |
| Clock | 1.33GHz |
| Memory | DDR3 1GB |
| Internal Hard Drives : | |
|
Number of Drives
|
2 |
| Drive Interface | SATA II |
| Supported RAID Levels | 0, 1,Normal (JBOD) |
| Drive Capacity | TS3200D0202(2TB) |
| TS3200D0402(4TB) | |
| LAN Interface : | |
|
Standard Compliance
|
IEEE802.3/3u/3ab |
| Speed and Flow Control | 10/100/1000 Mbps (Auto Sensing) |
| Number of Ports | 2 x RJ-45 (Auto MDIX) |
| USB Interface : | |
|
Standard Compliance
|
USB 2.0 |
| Connector Type | A type |
| Number of Ports | 2 x USB2.0 |
| UPS Interface : | |
|
Standard Compliance
|
D-Sub 9pin |
| Number of Ports | 1 |
| Key Feature : | |
|
iSCSI
|
Y |
| IP Camera | Y |
| Hot Spare : | |
| Hot Swap | Y |
| Replication | Y |
| Failover | Y |
| Amazon S3 | Y |
| Port Trunking | Y |
| Disk Quota | Y |
| Virus Scan | Y(supported from firmware version 1.11 or later） |
| Protocol Support : | |
|
Networking
|
TCP/IP |
| File Sharing | CIFS/SMB, AFP, HTTP/HTTPS, FTP/SFTP/FTPS, NFS |
| Directory Integration | Active Directory |
| Management | HTTP/HTTPS |
| Time Synchronization | NTP |
| Other : | |
|
Client OS Support
|
Windows® 8 (32/64-bit)/ 7 (32/64-bit)/ |
| Vista® (32/64-bit)/ Windows® XP | |
| Windows Server® 2012/ 2008 R2/ | |
| 2008/ 2003 R2/ 2003/ 2000 | |
| Mac OS® X 10.8/ 10.7/ 10.6/ 10.5/ 10.4 | |
| Power Consumption | 40W (Average), 47W (MAX) |
| Dimensions (LxWxH, ) | 230 x 170 x 170 |
| Weight | 4.5 kg |
| Operating Environment | 5-35°C, 20-80% (non-condensing) |
| Power Supply | AC 100-240V, 50/60Hz |
| Warranty | 3-year |
| Package Contents : | |
|
Contents
|
TeraStation 3200D (TS3200D) |
| Setup CD-ROM | |
| LAN cable | |
| AC Cable | |
| Front Panel Key | |
| Quick Setup Guide | |
| Warranty Statement |
