Suggested Use Case |
|
Hardware |
FORTIAP 14C |
Hardware Type |
Remote (Indoor) |
Number of Antennas |
1 interna |
Peak Antenna Gain |
2 dBi for 2.4 GHz |
Frequency Bands (GHz) |
2.400–2.4835 |
Frequency of Radio 1 |
2.4 GHz b/g/n |
Throughput |
Up to 150 Mbps |
Tx/Rx Streams |
1x1 MIMO 1 spatial stream |
Ethernet Ports |
5x FE RJ45 ports (1x WAN port, 4x LAN ports |
WME Multimedia Extensions |
Yes (4 priority queues for voice, video, data and background traffic |
Simultaneous SSIDs |
8 (7 if background scanning enabled) |
EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
User/Device Authentication |
WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist |
Maximum Tx Power |
17 dBm (50 mW) |
Mean Time Between Failures |
>10 years |
IEEE Specifications |
802.11b, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x |
Mounting Options |
Desktop, Wall |
Included Accessories |
AC power adapter and wall mount kit |
FortiPresence Capable |
Yes |
Dimensions |
|
Length x Width x Height |
3.86 x 4.92 x 1.06 inches (9.8 x 12.5 x 2.7 cm) |
Weight |
0.1 lbs (0.2 kg) |
Package (shipping) Weight |
1.2 lbs (0.56 kg) |
Environment |
|
Power Supply |
Adapter Input: 100–240V AC, 50–60 Hz |
Power Consumption (Average) |
3.35 W |
Power Consumption (Maximum) |
3.85 W |
Humidity |
20–90% non-condensing |
Operating Temperature |
32–104°F (0–40°C) |
Storage Temperature |
-13–158°F (-25–70°C) |
Directives |
Low Voltage Directive • RoHS |
Certifications |
|
WiFi Alliance Certified |
No |
Warranty |
|
Limited Lifetime Warranty |
Yes |
