Standards |
IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab |
|
1000BASE-T Gigabit Ethernet, IEEE 802.3ad LACP, IEEE 802.3z Gigabit Ethernet, IEEE |
|
802.3x Flow Control, IEEE 802.1D (STP, GARP, and GVRP), IEEE 802.1Q/p VLAN, IEEE |
|
802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE |
|
802.3af, IEEE 802.3at, RFC 768, RFC 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 879, RFC 896, RFC 826, |
|
RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 922, RFC 920, RFC 950, RFC 1042, RFC 1071, |
|
RFC 1123, RFC 1141, RFC 1155, RFC 1157, RFC |
|
1350, RFC 1533, RFC 1541, RFC 1624, RFC 1700, RFC 1867, RFC 2030, RFC 2616, RFC |
|
2131, RFC 2132, RFC 3164, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415, RFC |
|
2576, RFC 4330, RFC 1213, RFC 1215, RFC 1286, RFC 1442, RFC 1451, RFC 1493, RFC |
|
1573, RFC 1643, RFC 1757, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2233, RFC |
|
2618, RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 1157, RFC |
|
1493, RFC 1215, RFC 3416 |
|
|
IPv6 |
IPv6 host mode |
|
IPv6 over Ethernet |
|
IPv6/IPv4 Dual Stack |
|
IPv6 neighbor and router discovery (ND) |
|
IPv6 stateless address auto-configuration |
|
Path Maximum Transmission Unit (MTU) discovery |
|
Duplicate Address Detection (DAD) |
|
ICMP version 6 |
|
|
IPv6 ACL |
Drop or rate limit IPv6 packets in hardware |
|
|
Port mirroring |
Traffic on a port or VLAN can be mirrored to another port for analysis with a network analyzer or RMON probe. |
|
Up to 8 source ports can be mirrored to one destination port. Four sessions are supported |
|
|
Firmware upgrade |
● Web browser upgrade (HTTP/HTTPS) and Trivial File Transfer Protocol (TFTP) |
|
● Dual images for resilient firmware upgrades |
|
|
EEE compliance (802.3az) |
Support 802.3az Energy Efficient Ethernet on all ports; substantially reduce the power consumption when link |
|
bandwidth is not at full utilization |
|
|
Disable port LEDs |
LEDs can be manually turned off to save on energy |
|
|
Flash |
32 MB |
|
|
CPU memory |
128 MB |
|
|
Power |
100-240 V, 50-60 Hz, Internal |
|
|
Certifications |
UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, C-tick |
|
|
Dimensions (W x H x D) |
SF220-24, SF220-48, SG220-26, SG220-50 |
|
440 x 44 x 201 mm |
|
SF220-24P, SG220-26P |
|
440 x 44 x 250 mm |
|
SF220-48P, SG220-50P |
|
440 x 44 x 350 mm |
|
|
Weight |
SF220-24: 2.6 kg |
|
SF220-48: 2.98 kg |
|
|
