Product Description |
Cisco Small Business SG250-26HP - switch - 26 ports - smart - rack-mountable |
Warranty |
5 years for EOS |
Features |
DHCP support, BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), MLD snooping, reset button, LLDP support, 12MB packet buffer, Storm Control, SmartPort technology, Cisco Discovery Protocol |
Dimensions (WxDxH) |
44 cm x 25.7 cm x 4.4 cm |
Weight |
3.37 kg |
Power |
AC 120/230 V (50 - 60 Hz) |
Device Type |
Switch - 26 ports - smart |
Enclosure Type |
Rack-mountable 1U |
Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3az |
Capacity |
Active VLANs: 256 |
Remote Management Protocol |
SNMP, RMON, HTTP, HTTPS, TFTP, SCP |
Routing Protocol |
IGMP, static IPv4 routing |
Performance |
Switching capacity: 52 Gbps |
|
Forwarding performance (64-byte packet size): 38.69 Mpps |
Power Over Ethernet (PoE) |
PoE+ |
MAC Address Table Size |
8K entries |
Ports |
24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
Jumbo Frame Support |
9000 bytes |
PoE Budget |
100 W |
Subtype |
Gigabit Ethernet |
