| Standards | IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X |
| (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i | |
| (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) | |
| Ports | LAN Gigabit Ethernet auto-sensing |
| Cabling type | Category 5e or better |
| Antennas | Internal antennas optimized for installation on a wall or ceiling |
| LED indicators | 1 multifunction LED |
| Operating system | Linux |
| Ports | 10/100/1000 Ethernet, with support for 802.3af /at PoE, power port for AC adapter (included) |
| Buttons | Reset button, power on/off push button |
| Lock slot | Slot for Kensington lock |
| VLAN support | Yes |
| Number of VLANs | 1 management VLAN plus 8 VLANs for SSIDs |
| 802.1X supplicant | Yes |
| SSID-to-VLAN mapping | Yes |
| Auto-channel selection | Yes |
| Spanning tree | Yes |
| Load balancing | Yes |
| IPV6 | IPv6 host support |
| IPv6 RADIUS, syslog, Network Time Protocol (NTP) | |
| Layer 2 | 802.1Q-based VLANS, 8 active VLANs plus 1 management VLAN |
| WPA, WPA2 | Yes, including Enterprise authentication |
| Access control | Yes, management access control list (ACL) plus MAC ACL |
| SSID broadcast | Yes |
| Rogue access point detection | Yes |
| Multiple mounting options | Desktop or Wall |
| Physical security lock | Kensington lock slot |
| QoS | Wi-Fi Multimedia and Traffic Specification (WMM TSPEC), client QoS |
| Wireless throughput | Up to 1.2 Gbps data rate (real-world throughput will vary) |
| Recommended user support | Up to 64 connective users, 10 active users per radio |
| Web user interface | Built-in web user interface for easy browser-based configuration (HTTP, HTTPS) |
| Management protocols | Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour |
| Physical dimensions (W x D x H) | 5.31 x 5.31x 1.5 in. (135 x 135 x 38 mm) |
| Weight | 0.77lb or 350g |
