Model |
Cisco Aironet 1830 Series Access Points |
|
|
Software |
Cisco Unified Wireless Network Software Release with AireOS wireless controllers: |
|
● 8.1.121.0 or later for the Cisco Aironet 1830 Series Access Points |
|
|
Memory |
1GB RAM |
|
56MB Flash |
|
|
Data Transfer Rate |
1 Gbps |
|
|
Integrated antenna |
● 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360° |
|
● 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360° |
|
|
Interfaces |
● 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) |
|
● Management console port (RJ-45) |
|
● USB 2.0 (enabled via future software) |
|
|
Indicators |
● Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors |
|
|
Input power |
● AP1830: 44 to 57 VDC |
|
|
Requirements |
● Power supply and power injector: 100 to 240 VAC; 50 to 60 Hz |
|
|
Power draw |
● 15.4W |
|
Note: When deployed using a PoE specification, the power drawn from the power sourcing equipment will be higher |
|
by some amount, depending on the length of the interconnecting cable. |
|
|
Powering options |
● 802.3af/802.3at |
|
● Enhanced PoE |
|
● Cisco local power supply, AIR-PWR-C= |
|
● Cisco power injector, AIR-PWRINJ5= (Note: This injector supports 802.3af only), AIR-PWRINJ6= |
|
Note: If 802.3af PoE is the source of power, the USB port is disabled. |
|
|
Dimensions(W x L x H) |
Access point (without mounting bracket): 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
|
|
